Hisaka Heat Exchangers

Hisaka is a globally recognised Japanese manufacturer of plate heat exchangers, known for its wide range of herringbone, washboard, and special-pattern plate designs used across chemical, marine, power, food, and general industrial applications. SRJ is a Hisaka Plate Heat Exchanger Manufacturer of compatible replacement parts - we produce Hisaka replacement plates and Hisaka gaskets engineered to match the original port layout, plate pattern, and clamping dimension, so units already installed in your plant can be re-plated and re-gasketed without any change to the existing frame.

Our Hisaka compatible plates and gaskets cover the LX, UX, RX, SX, EX, FX, GX, and YX series, available in SUS304, SUS316/316L, and Titanium plate materials, with gaskets supplied in NBR, EPDM, IIR (butyl), FPM (Viton), and silicone compounds. As a dependable source of Hisaka Plate Heat Exchanger Parts, every plate and gasket we manufacture is dimensionally checked and pressure-tested before dispatch, giving plant engineers and procurement teams a reliable, drop-in alternative to long OEM import lead times from Japan.

SRJ manufactures Hisaka replacement plates and Hisaka compatible gaskets pressed on tooling matched to original port position, plate pattern, and gasket groove profile across the full Hisaka model range - LX, UX, RX, SX, EX, FX, GX, YX, NX, and CX series. Because each plate reproduces the original plate type, thickness, and frame-fit dimension exactly as coded in Hisaka's own naming convention, it seats correctly on the guide bar and carrying bar of your existing frame without requiring modification to the frame, tie bolts, or tightening arrangement.

Hisaka organises its plate range into three broad pattern families. The herringbone pattern covers the LX, UX, RX, SX, and CX series - LX plates use a rougher, deeper corrugation pitch suited to low-NTU (Number of Transfer Unit) duties, SX plates use a finer, shallower pitch for high-NTU applications, and UX/RX sit in between the two. The washboard (corrugated) pattern covers the EX and FX series, offering fewer metal contact points, which makes it well suited to fluids containing fibres, particles, or sludge - the FX series in particular was developed for food-grade applications. The special-pattern range covers the GX series, engineered for fluids with high slurry content or high viscosity, and the YX series, developed exclusively for vapour condensation duty.

As a Hisaka Plate Heat Exchanger Manufacturer of compatible parts, SRJ reproduces Hisaka's own model naming logic in its manufacturing specification - series name, plate size code, plate pattern, plate thickness, and gasket-fixing method - so that a replacement plate ordered against your existing Hisaka model code (for example, an RX or LX series unit) matches the original in every dimension that affects fit and thermal performance. Gaskets are supplied as slit-in (glue-free) or slit-in (glued) types, following the same fixing method as your original Hisaka gaskets, so plate pack reassembly during maintenance proceeds exactly as your team is used to.

Material options for Hisaka compatible plates include SUS304 and SUS316/316L for standard industrial and process duties, and Titanium for aggressive or corrosive media - matching Hisaka's own standard material stock policy, which keeps common grades readily available for fast turnaround. Higher-grade materials such as high-nickel alloy can also be manufactured to order for specialised chemical or marine applications. Gaskets are available in NBR for oil and hydrocarbon media, EPDM for water and general process duties, IIR (butyl) and FPM (Viton) for higher-temperature or more chemically aggressive conditions, and silicone where required - and for highly corrosive fluids beyond the resistance of conventional elastomers, SRJ can also produce PTFE cushion-type gasket configurations similar to Hisaka's own PTFE gasket development.

SRJ's in-house Noida facility allows Hisaka replacement plates and gaskets to be manufactured to order, supporting both recently installed Hisaka LX/UX/RX/SX/EX/FX/GX/YX units and older or discontinued Hisaka models where genuine Japanese OEM spares can mean lengthy import lead times and higher landed costs. Every production batch is backed by our ISO 9001:2015 certified quality process - dimensional and flatness checks on plates, groove-fit verification on gaskets, and pressure testing of assembled plate packs on request - giving your procurement team a documented basis for approving non-OEM Hisaka compatible plates and gaskets.

Don't see your exact model listed? Send us your Hisaka nameplate details or an existing plate sample - we manufacture Hisaka compatible plates and gaskets to your specific unit's dimensions, including older or discontinued Hisaka models.
